Name: Ohaus FW Industrial Platform Scales + Ohaus DT33P Indicator
SKU: 3430
Availability: instock
Rating: 5 (1 reviews)

Ohaus FW Industrial Platform Scales + Ohaus DT33P Indicator

Our Price: £531.00 – £904.00 + VAT (£637.20 - £1,084.80 inc VAT)

Ohaus Industrial Platform Scale – Strong, Reliable, Affordable, many stocked in the UK for fast delivery!

Add Calibration Certificate

Description

Ohaus FW Industrial Platform Scale + Ohaus DT33P Indicator – Heavy Duty, Strong, Reliable, Affordable

The Heavy Duty FW Ohaus platform scale + Ohaus DT33P is ideal for general industrial applications such as weighing pallets of different sizes and other heavy items.

Designed for pallet weighing and other heavy duty, industrial weighing applications where a strong, reliable and affordable low cost mild steel weighing platform is required. The Ohaus FW + Ohaus DT33P pallet weighing platform scales are built to a high standard and come with a high quality Ohaus DT33P indicator as standard. 4 OIML R60 C3 approved IP67 mild steel load cells and threaded eyebolt holes for easy lifting. The Ohaus DT33P indicator has a high-impact durable ABS housing and a large backlit LCD display.

If Trade Approved is required for buying and selling by weight, please tick the box near the product description.

IP Rated Stainless Steel version also available for washdown/harsh environments, see here.

Test weights for these scales available here.

Ramps available. Please see Product Options below

Applications: Weighing, Counting, Checkweighing, Totalization

Weighing Units: kg, g, lb, oz, lb:oz

Interface: RS232

Power Supply: 100-240 VAC / 50/60 Hz Universal Power Supply

MPN:

FW-0808

FW-1010

FW-1212

FW-1515

FW-1812

FW-2015

Downloads

We endeavour to deliver your goods to you as fast as we can. A large percentage of our orders are delivered in 3 - 5 working days (all mainland UK postcodes except IV, AB and KW) but some goods can take longer if they are delivered direct from the manufacturer or if the item is made to order. Please note, IV, AB and KW postcodes and non-mainland UK including Northern Ireland can take longer. Please give us a call if your order is urgent to verify the delivery time or see if a faster delivery is possible (additional costs may apply for larger orders).

The following delivery charges may apply per order:

£12.00 + VAT – Mainland UK
£30.00 + VAT – UK non-mainland

Reviews

There are no reviews yet.

Be the first to review “Ohaus FW Industrial Platform Scales + Ohaus DT33P Indicator”

Key Accessories

FW-RP-1515 - Mild Steel Ramp (x1)

Our Price: £187.00 + VAT

FW-RP-1010 - Mild Steel Ramp (x1)

Our Price: £139.00 + VAT

FW-RP-1212 - Mild Steel Ramp (x1)

Our Price: £167.00 + VAT

FW-RP-0808 - Mild Steel Ramp (x1)

Our Price: £120.00 + VAT

Frequently Asked Questions

Please see below for answers to frequently asked questions.

Are readability and accuracy the same thing?

No, although they are both useful measures of weighing equipment performance. Readability refers to the smallest increment of weight that scales or balances will display. A readability of 0.5g, for example, means the scale would display an item of 10.503g’s weight as 10.5g and an item of 10.805g as 11.0g.

Accuracy is a measure of the possible difference between the displayed weight and an item’s real weight. It is often displayed as a percentage. An accuracy of +/- 1% means the scale could measure 100g as anywhere between 99g and 101g.

Do I need a calibration certificate?

A calibration certificate proves the accuracy of your weighing equipment. It is very likely that if accuracy matters in your workplace, certification will be required by your industry regulators. They are straightforward to get hold of though. Just ask our team.

Do I need a "Verified For Trade Use" scale?

If you are trading or transacting anything by weight, you will probably need to demonstrate your weighing equipment is verified for trade use. This gives your customers confidence in your business and will make sure buying and selling run smoothly. We can help get you with relevant approvals for your equipment.

How often should I have my scales calibrated?

The answer will vary depending on how your equipment is used. As a minimum, we typically recommend once a year but our team can provide advice based on your individual circumstances.

Which class of test weight should I use?

The International Organization of Legal Metrology (OIML) has established standards for the classification of calibration test weights. Varying from E0 & E1, which are the most accurate to M2 which are commonly used for calibrating platform scales, floor scales and other industrial weighing instruments.

As a rough guide we have listed desired accuracy against class below.

+/- 0.1% – UNclassed Proof Load Test Weights
+/- 0.05% – M3 (Check/calibrate coarse scales)
+/- 0.005% – M1 (Check/calibrate standard scales)
+/- 0.0015% – F2 (Check/calibrate portable balances)
+/- 0.0005% – F1 (Check/calibrate precision balances)
+/- 0.00015% – E2 (Check/calibrate analytical balances)

The choice of weight class depends on the intended use and the level of accuracy required for a particular application. If you’re unsure, talk to our team who can advise you on the right class for your equipment.

How to pack a scale for shipping

If you’re sending a scale back to us for recalibration, it is ideal to use the original packaging. If this is not available choose a sturdy well-padded box to avoid shocks. Where possible, protect the load sensor by removing the weighing pan and any under-pan support and pack these separately in the box. You may be able to use the equipment’s locking pins or screws too.

Do ensure all the paperwork, including your contact details, is included to ensure we can return it once calibration is complete.
