Ohaus MB120 Moisture Analyser

Professional Moisture Analyser For Advanced Moisture Analysis

Faster, Smarter, More Efficient Moisture Analysis!

Moisture affects everything we use on a daily basis therefore in many cases it is important to be able to accurately determine the moisture content of samples. Equipped to handle routine and sophisticated measurements, our flagship MB120 moisture analyzer makes the whole process faster, easier, and more efficient. The MB120 allows you to analyze more samples, access saved data, and spend less time prepping and more time putting your results to work.

Unique Features:

•Get started quickly with SmartGuide™. This revolutionary feature automatically analyzes a sample and creates a method, thereby removing the guesswork from the initial setup.

• The MB120 has the capability to produce fast and accurate results due to features such as a halogen heating system, customizable shut-off criteria and four built-in drying profiles.
• The MB120’s allows storage of up to 100 methods and 1,000 measurement results. Stored results can be exported and methods can be shared across multiple devices.

Simple and Powerful Moisture Analysis!

• SmartGuide™

SmartGuide™ automatically analyzes a sample and creates a method, simplifying the method creation process and removes the guesswork
from the initial setup.

• Fast and Efficient Halogen Heating Technology
Halogen heating dries samples efficiently and in a fraction of the time versus a traditional MB120 has a full operating temperature range of
40–230 °C, settable in 1-degree increments.

• Uniform Drying for Precise, Repeatable Results

The reflective sample chamber ensures uniform heating of each sample to yield reliable results of 0.01 % readability.

• Four Drying Profiles

Customize heating of specific samples with various drying programs; Standard, Fast, Ramp, and Step.
Fast: Quickest possible time to temperature
Standard: Minimal overshoot while achieving temperatures quickly
Ramp: Controlled ramping to temperatures

Step: Set three temperatures at three time intervals

• Flexible and Configurable Shut-Off Criteria

Customize your own test endpoint criteria to automatically end the test once moisture loss is no longer detected. Choose one of the built-in
standard criterion or define your own.

Advanced Functionality

• Internal Method Library
Store methods for up to 100 different samples – methods can be easily recalled and transferred to other units for quick setup.

• Internal Result Storage
The MB120 will store 1000 results which can be group or individually for further analysis.

• User Management
With User Management, MB120 provides operational control and aids compliance by restricting access so that unauthorized users may use the device but not change settings.

• RS232 and USB Ports
Quick connections to a printer, PC or flash drive.

Easy to Use and Maintain

• Graphic Display with Touchscreen
Navigate the device easily with an intuitive user interface on a bright, color, and easy-to-read graphic display.

• Icon-Driven Menu Navigation
Easy to follow — no training required

• 4 Mechanical Keys for Fast One-Step
Operation Tare, Start/Stop, Print, On/Off

• Easy Tool-Free Cleaning
Stainless steel surfaces are resistant to corrosion and wipe down quickly. Heating chamber components can be easily removed for easy
cleaning – no tools required.

Compliance:

• Product Safety: IEC/EN 61010-1; IEC/EN 61010-2-010; CAN/CSA C22.2 61010-1; CAN/CSA C22.2 61010-2-010; UL 61010-1; UL 61010-2-010

• Electromagnetic Compatibility: IEC/EN 61326-1 Class B, Basic environments; FCC Part 15 Class A; Canada ICES-003 Class A

• Compliance Marks: CSA, CE, RCM, WEEE

Applications:  Percent Moisture Determination, Percent Moisture Regain Determination, Percent Solid Determination, Weighing

Display: 4.3″ TFT color touchscreen display

Operation:  Power cord (included)

Communication:  RS232 with GLP/GMP data output, USB Host and USB Device (included)

Construction:  Metal base, ABS top housing, halogen heat source, stainless steel pan support, stainless steel pan handler, in-use cover

Design Features:

Seven shut-off criteria (manual, timed, autofree %/s, autofree mg/s, A30, A60 and A90), four drying profiles (standard, fast, ramp and step), storage up to 100 methods and 1000 test results for all methods, user guide, 40°C to 230°C heating temperature range (1°C increments), 14 operational languages.

Heating Technology: Halogen Lamp

Capacity / Readability / Moisture Content Display: 120g / 0.001g / 0.01%

Drying Temperature: 40°C – 230°C

Measurement Mode: Moisture Content (Wet or Dry Base) / Weight (g)

Measurement Programs: Standard Mode, Fast Mode, Ramp Mode and Step Mode

Interface: RS-232, USB Host, USB Device

Power Supply: 130 or 240 VAC, 50/60 Hz

On-site demonstration available for this product
